ERROR MANAGEMENT TRAINING IN COMPUTER PROGRAMMING COURSES THROUGH A SYSTEM OF TASKS

Lasko M. Laskov
OrcID: 0000-0003-1833-8184
WoSID: K-7516-2012
E-mail: llaskov@nbu.bg
New Bulgarian University
Department of Informatics
21 Montevideo Blvd.
1618 Sofia Bulgaria

Резюме: Errors are an indivisible part of computer programming, and as such their incorporation as a tool in teaching is a natural approach to stimulate learners to be an active side in the educational process. The application of errors as an instrument for illustration of knowledge, and the encouragement of students to learn from them, is the main approach of Error Management Training (EMT). EMT has been shown in number of psychological studies (Frese 1995; Keith & Frese 2008; Dyre et al. 2017) as an efficient teaching technique, even compared to the traditional error-avoidance methods. In this paper we present an application of EMT in computer programming courses, based on different approaches for error handling, which must be an important part of the curriculum.

Ключови думи: computer programming; informatics education; programming errors; error management training; teaching through tasks

1. Introduction

In the introduction of the chapter Errors of his book (Stroustrup 2014), Bjarne Stroustrup emphasizes: What we are trying to do is to show what “thinking like a programmer” is about. Indeed, errors are such an indivisible part of the process of computer programming that the attitude to them and the techniques for error handling largely determine the cognitive process involved in software creation. Even a novice programmer inescapably understands that it is nearly impossible to implement yet a simple program without any errors. In the case of real-life complex applications this rule is even carried to extreme, and different approaches to error handling must be combined together to ensure that the final version of the source code will be relatively safe and suits the tasks which it is intended for.

During the implementation and testing of a computer program errors cannot be avoided. Instead, during the different stages of the process, they have to be discovered, solved, and even predicted – and still a well written program code will possess a high level of confidence for robustness, but never full faultless. Exceptional situations and their handling are turned into a tool for verification of software correctness, and as such the correct approach to them helps the creation of the source code. Thus, it is also natural to incorporate errors as an important teaching tool in computer programming courses.

Of course, error handling mechanisms are a classical part of the curriculum of computer programming courses (Stroustrup 2014; Horstmann & Budd 2008; Horstmann 2019; Laskov 2016) and are usually taught using the traditional error-avoidance methods. In other words, exceptional situations are explained mainly from the precondition goal to escape from them, which is a natural and straightforward approach. However, an innovative teaching paradigm suggests to bring the errors to the foreground of the learning process, and to encourage learners to experiment with them, and learn from them: the Error Management Training (EMT).

EMT has been compared to the traditional error-avoidant methods and it has been shown as a superior teaching technique in number of psychological studies (Frese 1995; Keith & Frese 2008; Dyre et al. 2017). It has been shown that EMT aims to overcome the emotional negatives of making mistakes (Heimbeck et al. 2003), which is a common obstacle for the students in a beginner’s course of computer programming.

In our practice we adopt the approach of teaching computer programming by formation of notions through a system of tasks (Asenova &Marinov 2018, 2019; Laskov 2021). In this context, the transfer of knowledge may be improved by encouraging learners to make errors intentionally (Dyre et al. 2017) – a technique that is natural in the case of computer programming training, since exceptional situations themselves can be used to depict clearly different practical aspects in the tasks.

In this paper we put errors and error handling mechanisms in the center of creation of a system of tasks for computer programming courses in three different levels of complexity: basic, advanced and intermediate. These levels are determined by observing the relative effort of the learners to develop the notions needed to describe the causes of the errors. These levels of complexity are used to describe system of tasks used in the following computer programming courses:

1. Introduction to computer programming.

2. Object-oriented programming.

3. Data structures.

We provide a short discussion of different types of errors in computer programming. The classification scheme of programming errors is applied in the EMT approach to the system of tasks that form the three levels of courses complexity.

We will discuss the alternative methods for error handling and we show how we build a system of tasks that use errors as the main teaching instrument.

2. Error classification

2.1. Evolution of classification systems

Software bug is one of the most common slang words indicating error in a computer program that was used so extensively that it even became an official term. The most popular version about the first usage of the word “bug” in the context of computing was told by Grace Hopper and it was that a moth was found in one of the relays of the Harvard Mark II computer in 1945 – see pp.205 – 206 of (Horstmann and Budd 2008). However this term was used before that and the first documented occurrence of “bug” in relation to computing was in a Bob Campbell’s entry in the logbook of ASCII/Mark I computer in April 1944 (Cohen 1994). Despite its popularity, there is no widely established error classification scheme applicable both in software development and education in computer programming. There are many extensive research works on software reliability analysis, historically starting from the late the seventies of the last century.

An early research in the technical report (Motley & Brooks 1977) suggests linear regression analysis application to predict statistically programming errors. The subjects of analysis are linear combinations of program characteristics (used to measure the complexity of the program) and programme variables. Program exceptional situations are defined as errors that are found during the formal testing, can be attributed to the programmer, and require changes in the source code of the program. The errors are classified in eight categories: logic, data handling, interface, data input/output, computational, other, data bases, data definition. Some errors are not classified as programming errors, but still they are result of the development process: requirements specification, design, coding, maintenance (correction of errors).

Another early work (Bowen 1980) compares the state of the art for that time error classification schemes and proposes error categories and subcategories. The classification scheme is based on comparison of the application to multiple projects and attempts to avoid excess granularity. Three categories to provide feedback are defined: source (the phase where error occurs), cause (casual description), and severity (effect of the error). Seven major categories are proposed to support software reliability analysis: design, interface, data definition, logic, data handling, computational, and other.

A notable work is proposed by Donald Knuth (Knuth 1989) in which he provides an extensive analysis of the errors during the evolution of his famous TEX project during a period of ten years. He presents error classification into fifteen categories: A (algorithm), B (blunder), C (cleanup), D(data), E (efficiency), F (forgotten), G (generalization), I (interaction), L (language), M (mismatch), P(portability), Q (quality), R (robustness), S (surprise), T (typo). Further, Knuth classifies the categories in two classes:

• “bugs” – programming errors that obligatory have to be corrected (A, B, D, F, L, M, R, S, T);

• enhancements – situations that can be considered as conditions for enhancement, rather than errors.

Also, the categories are classified with respect to their difficulty:

• simple (T, B, F, L, M);

• technically more complex (A, D);

• special situations from which the program must recover even in wrong input (R);

• complex interactions between different parts of the program (S);

• various types of enhancements during the development of the system (C, E, G, I, P, Q).

Knuth points out that the presented classification scheme is ad hoc, and it relies on the functionality of the program, rather than attempting to classify the particular programming errors, like for example misuse of a given operator from the programming language. Thus, this classification scheme is not focused on teaching computer programming; however it clearly shows a scheme for analysis of evolution of a complex project by tracking down the categories of errors. Also, the errors that are cause of wrong initial ideas in the algorithm are clearly separated in the category A. Besides the above fundamental works, a contemporary approach to software errors classification scheme is based on software engineering approach. In the (Ko & Myers 2003) and (Ko & Myers 2005) the authors propose a model of programming errors that is based on an extensive survey of the existing error classification schemes and error causes analysis. Most of the errors are reported to be a result of problems in implementing algorithms, language constructs and uses of libraries.

2.2. Application in education

The above error classification schemes are either result of analysis of complex software projects, or are directly designed to serve the software development process. Even though they are closely related, these classification schemes are not created to aid the educational process. Something more, often when teaching computer programming, the error classification systems are simplified.

Often the focus is on logic (semantic) errors, which is a natural approach because for novice programmers these types of errors are most difficult to resolve. For example, in (Ettles et al. 2018) logic errors are classified in three categories: algorithmic errors, misinterpretation of the task, fundamental misconception. The misconception is concluded as the most frequent and difficult for students.

It is a common approach in the educational literature to list the general categories of errors that are used in the consecutive examples. For example, in (Horstmann and Budd 2008), p.666 the author lists the following types of errors that are used to illustrate the usage of the mechanism of exceptions: user input errors, device errors, physical limitations, component failures. On the other hand, Stroustrup uses the following classification in (Stroustrup 2014): compile time errors (syntax errors, type errors), link-time errors, run-time errors, errors detected by the computer (hardware and OS), errors detected by a library, errors detected by user code, and logic errors. The latter approach is close to the real-life analysis of complex projects, but still is well-suited for the educational purposes, because it is not too granulated (as it was mentioned in (Bowen 1980)).

We must also point out that the error classification schemes may vary depending on the programming language being used. For example, if we consider the classification scheme in (Stroustrup 2014), the errors in the linking step cannot be directly applied in the case of Java programming language (Horstmann 2019; Eckel 2011). And vice versa, some mechanisms in Java (like checked and unchecked exceptions) are not directly applicable in C++ programming language, and for that reason the errors that are classified to be handled by these mechanisms cannot be directly transferred.

2.3. Proposed classification scheme

The complex and too detailed error classification schemes like those in (Bowen 1980; Knuth 1989; Ko & Myers 2003, 2005) are not suitable for our purposes in the courses in computer programming that are designed for absolute beginners. On the other hand, since the examples used in our curriculum use errors as an instrument for knowledge formation, we cannot adopt the approach towards errors which otherwise is successful in the standard error-avoidance educational methods. See for example (Horstmann & Budd 2008) and (Laskov 2016).

The above motivates us to propose our error classification scheme (Fig. 1) that is applicable in the case of EMT in computer programming. Our programming courses are designed using the C++ programming language, and for that reason naturally the technical aspects of our scheme are highly influenced by those proposed in (Stroustrup, 2014). We will point out that the selection of the programming language will not limit the described approach. For example, with few technical modifications, it is absolutely applicable in courses built based on Java programming language (Horstmann 2019; Eckel 2011).

The error classification scheme (Fig. 1) is hierarchically organized and has a tree structure. The root of the tree is the general category error. The error category is divided in two separate classes:

1. Internal: represents all errors that are direct result of constructions that comprise the computer program.

2. External: represents all errors that result from circumstances that are not part of the program itself.

Figure 1. The tree structure of the proposed error classification scheme.

The internal category consists of:

Language: these are all errors that violate the formal rules of the programming language and the accepted style. They can be one of the following two subcategories.

Rules: the errors that violate the rules of the language. In the case of C++ an error can be caused in the preprocessing, in the compilation or during the linking step. In our courses we pay an extra attention to compiler warnings as well.

Style: many programming environments and languages have their widely accepted style rules which are not part of the programming language itself.

They include code formatting, program elements naming, code organization in source code files. We distinguish between widely accepted style rules, and some rules that are imposed specifically for the purposes of our courses. For example, in our courses we pay special attention to sourcecode formatting, and program elements naming rules. Also, we insist that the main() function of a C++ program always ends with return 0; statement, even generally it could be omitted (Stroustrup 2014).

Semantic: these are logical errors, and are the category of errors that are hardest to find and correct. Logical errors can be in the very idea of the program or the algorithm itself. They can be caused by the selection of wrong data structures, or in data structures implementation itself. Also, we will consider a semantic error, when a function or routine of the program is not used correctly (for example calling the sqrt() function with a negative argument).

The external category consists of:

Input: these are all types of errors that result from wrong input to the program from both user and other programs. These types of errors are not the same as the wrong function input that are classified in the semantic category of internal errors, mostly because the input to the program is often not controlled by the programmer. However, a programmer may try to predict the wrong program input, and make the program code robust against these types of external circumstances.

Resource: these are errors that arise because of a missing resource, such as missing file, failed network connection, or failed database connection. Different frameworks have tendency to handle differently these types of errors, for example in Java the mechanism of checked exception deals with missing resources.

System: the programmer has to consider that the system itself, on which the software is running, may possibly fail. For example, a hardware device may go out of order, or the OS may malfunction.

Besides the above described error categories in the hierarchical structure, we will distinguish two categories that are most often emphasized during programming courses:

1. Compile-time errors: these are errors and warnings that are generated by the compiler during the compilation process of the program. Apparently, the errors from the rules category fall inside this category. Note that in particular cases, errors from other categories, may also lead to compile-time errors.

2. Run-time errors: these are errors that are encountered during the execution of the program. They do not violate the rules of the programming language and are not caught by the compiler. For example, the errors from the input category are run-time errors.

These two error categories are described outside the hierarchy structure on Fig. 1 because they introduce another classification scheme with the respect of the compilation process and execution of the program. Also, a category may be classified as a compile-time error or a run-time error depending on the programming language being used. For example, a missing file may cause a run-time error in a C++ program, but it will result in a compile-time error in Java.

Something more, many programming languages have mechanisms that attempt to reduce the runtime errors to compile-time errors. Such mechanisms are for example the checked exceptions in Java (Horstmann 2019; Eckel 2011), or constant function parameters and constant member functions in C++ (Stroustrup 2014; Horstmann & Budd 2008; Laskov 2016). In the design of the system of task in our courses, we pay extra attention to these language constructions.

3. Error handling mechanisms

Error handling mechanisms have been evolving together with the programming paradigms and programming languages, and as a result different alternative approaches exist (Koenig & Stroustrup1990; Horstmann &Budd 2008). For the needs of a computer programming course, we must consider the programming paradigm and language, but also the appropriate complexity of the selected approach.

The methods that are used in our programming courses are mainly influenced from the selection of the C++ programming language, but also consider the legacy of the C programming language. For that reason we combine features presented in (Stroustrup 2014; Koenig & Stroustrup 1990; Horstmann& Budd 2008) to achieve the following system of alternative error handling mechanisms.

3.1. Assume that no error will occur

Definitely the easiest approach, and of course the less applicable in the development of real-life applications, is to assume that no error will occur at all, and not to try to handle any exceptional situations. On the other hand, this attitude towards errors is practical in the case of the basic level of complexity of examples. From the point of view of EMT this approach is actually appropriate, because the errors that we would like to emphasize can stand out.

Task 1. A function circleRad()takes as a parameter the area A of a circle and calculates its radius r. Recall that r = \(\sqrt{\cfrac{A}{n}}\) where p= 3.141592654 must be a global constant. Trigger the function with a negative argument.

double circleRad(double area)
{ return sqrt(area / PI);}

Listing 1. Calculate circle radius, given its area. Function assumes no error will occur.

The implementation of the function that is given in Listing 1 assumes that no error will occur, and if the argument is a negative number, the sqrt() function will return -nan. Note that the minus sign in front of the not-a-number constant is a result of its intrinsic representation: all the bits of the exponent of the floating-point number are set to 1, while the mantissa remains as it is, so is the bit that represents the sign of the number.

In the proposed classification of errors, this is an error of type semantic/ function misuse.

3.2. Output error message

Another basic technique to treat error situations is simply to output an error message either to the standard output, or to a log file for more complex examples. This approach is also not very practical, however in basic examples it gives a good representation where and why an error can happen.

double circleRad(double area)
{ double result = 0.0;
if (area < 0)
{ cerr << “Negative area.” << endl;}
else{ result = sqrt(area / PI);}
return result;
}

Listing 2. The circle radius task solved with error message in case of negative input.

Note that using the solution in Listing 2 the error is detected and it is displayed in the standard error output stream, however the program flow is not interrupted, and the function will even return a value in case of exceptional situation. This approach is also suitable in the cases students have to implement fast solution of a given task, for example during an exam, and they need a simple mechanism to reduce the amount of errors in their code.

3.3.Terminate program with an error message

In this error handling technique, once an error is detected, a message is displayed, and the program is terminated. On the first glance this might appear quite ruff approach, and definitely is not the best way to deal with exceptional situations in real-life applications. However, this technique is extremely suitable for prototyping, and it may help programmer to reduce the mistakes in the initial version of the code. In C and C++ it is easy to implement it using the assert() macro (see Listing 3 below).

double circleRad(double area)
{ assert(area >= 0);
return sqrt(area / PI);
}

Listing 3. The circle radius task solved with assertion to terminate the program with error message.

In this case we proceed from the assumption that detected errors must be eliminated from the final version of the source code. For that reason this technique is used in the tasks of intermediate complexity, for example in the initial implementation of some data structures such as linked lists, stacks and queues.

3.4. Return flag or external flag

In all previous error handling techniques, the error is detected inside the function, and it is processed again inside the function. In many situations in the practice, the error can be detected in the function, but it has to be processed in another program scope, very often where the caller of the function is. One of the standard techniques to achieve this effect is to signal to the functional caller the error using the return value of the function (Listing 4).

double circRad(double area)
{ double result = -1;
if (area >= 0)
{ result = sqrt(area / PI);}
return result;
}

Listing 4. The circle radius task solved with return value denoting the error state.

Another approach is to set the value of a global flag. In C++ many mathematical routines use this way for error signalling. In Listing 5 we trigger the function circRad() (its initial version in Listing1) causing function misuse error. The sqrt() function will set the global flag errno to the state EDOM value that indicates a domain error.

errno = 0; // reset the error flag
circRad(-1);
if (errno == EDOM) // domain error
{ cerr << “circRad() caused a domain error.” << endl;
}

Listing 5. The function misuse error indicated using the global flag errno set by sqrt()function.

Since error handling using return values and flags is typical for procedural programming languages, it is widely used in standard library functions inherited from the C programming language, and students must be familiar with it.

3.5. Error handler functions

Another approach that is also used in some standard libraries in C++ includes the error handler functions. The library provides a function that is triggered when exceptional situation is detected. For example consider the following function:

void error(){ action();}

The function action() is declared as a pointer to a function void (*action)();.The user implements a function that defines the action that must be taken, when the error occurs, so it can be set using the following installation function:

void setErrorAction(void (*userAction)())
{ action = userAction;}

Now the user can implement the function that determines how exactly the error will be handled

void argError()
{ cerr << “Wrong argument.” << endl;}

and then installs it using the call setErrorAction(argError);. Then our circle radius example will be as given in Listing 6.

double circleRad(double area)
{ double result = 0.0;
if (area < 0){ error();}
else{ result = sqrt(area / PI);}
return result;
}

Listing 6. The function misuse error processed using error handler function.

Even though this approach can look limited from a given point of view (Horstmann & Budd2008), it is actually quite powerful (Koenig and Stroustrup 1990), especially when using the principles of functional programming that are also available in C++ programming language. Also, note that errorhandler functions are used by low-level memory management system of C++, and hence a student at the advanced level must be familiar with them.

3.6. Exceptions

Exceptions exist in C++ since C++98 standard, and they have the tendency to replace the older mechanisms for error handling in many systems. In (Koenig & Stroustrup 1990) Stroustrup and Koening give the following motivation for exception handling mechanism: A library routine can detect an error, but it cannot process it. A routine that is a user of the library knows how to process an error but it cannot detect it.

In many cases we can consider that mechanism of exceptions, as Stroustrup and Koening point out, is more readable, more regular in style and more integrable with other parts of the program, compared to the alternative mechanisms to handle errors within a library. See also (Stroustrup 2019).

In some programming languages exceptions are even an indivisible part of the language. Java is an outstanding example (Horstmann 2019; Eckel 2011) with its mechanism of checked exceptions that will not allow the program to compile in the case they are not handled. However, we must also consider that exceptions are criticised (Sutter 2019), and even there are frameworks based on C++that do not allow exceptions – for example Qt (Eng 2019).

double circleRad(double area)
{ if (area < 0)
{ throw logic_error(“Illegal parameter value.”);}
return sqrt(area / PI);
}

Listing 7: The function misuse error resulting in throwing an exception.

The circle radius example from above, implemented using exception throwing in Listing 7, shows the compactness and clearness of the error handling code using this mechanism. The fact that exceptions can be caught exactly in the scope of the program in which the code can recover successfully from the error shows its flexibility. In our courses on both intermediate level and advanced level exceptions are widely used, especially in advanced implementations of data structures such as trees, priority queues, heaps, maps and hash tables.

4. EMT based system of tasks

In contrast to the standard error-avoidance educational methods, EMT uses errors as an instrument to illustrate knowledge and develop skills. Students are not taught directly how to avoid errors, but actually are encouraged to provoke them, to analyze what causes them, techniques to handle, and correct them. Using a system of tasks that are formulated based on this principle, we show how complex notions can be formed and practical skills are developed. In this section we present few example tasks taken from our system of tasks that form the curriculum of our computer programming courses. Each task is classified with respect to the following features: complexity, course, error, and handling mechanism. The classification that we provide (given as a table in front of each task) is based on the proposed error classification scheme and error handling mechanisms.

complexitycourseerrorhandling mechanismbasicIntroduction to computer programmingpreprocessor, compiler, course specicassume no error will occur

Task 2. Try to compile the “Hello, World!” program by consecutively omitting the following lines:

#include <iostream>
using namespace std;
return 0.

When the student tries to compile the program with the omitted include preprocessor directive, the compiler responds with error message ‘cout’ was not declared in this scope, and also suggests that std::cout is defined in header <iostream> did you forget to #include <iostream>?. Even though the error is generated by the compiler, we can classify it as a preprocessor error, because the problem is a missing preprocessor directive. This error clearly shows that the basic I/O system of C++ is not part of the core of the language; rather it is defined in a standard library.

Omitting using namespace std; introduces the notion namespace. Also this compile-time mistake is very common for novice programmers. Besides that, this error opens the discussion whether it is a good style to use the using namespace construction, or it is better to use the namespace with scope resolution operator.

The last error from Task 2 is an example of style/course specific category. In many literature sources omitting the return statement at the end of the main() function is not considered an error, however in our courses we have decided to label it as a bad style, because of the formal rule that a function must return data compatible with its return type.

complexitycourseerrorhandling mechanismbasicIntroduction to computer programmingsemantic/algorithmreturn ag

Task 3. The sphere volume is given by the following expression: \(V=\cfrac{4}{3}\pi r^{3}\) , where r is the radius of the sphere. Write a program that reads the radius r of a sphere from the standard input and calculates its volume using the expression: double volume = 4/3*PI*r*r*r;. If the calculated volume is not a valid value, return flag -1. Why the answer produced by the above code is not correct?

The error demonstrated in Task 3 shows the difference between integer division and floating point division. The usage of wrong operation, even though the cause of this error can be misunderstanding of the language rules, is a semantic error in the logic of the algorithm that is very common and hard to find by beginners.

complexitycourseerrorhandling mechanismintermediateIntroduction to computer programmingsemantic/ function misuseterminate program with an error message

Task 4. Implement a program that generates a string of small Latin letters with random length and random content. Consider the function randString() given below.

string randString(int max_size)
{ assert(max_size >= 0); // assert function input
int size = 1 + rand() % max_size;
string result;int i = 0;
while (i < size)
{ result.push_back(randSmallLatin());i++;}
return result;
}

How the program will behave in negative inputs? What is the result, if there is no call to the srand() function?

The example in Task 4 shows how the input of a function can be verified using assertions –a technique that is widely used in our courses on intermediate level. Also it helps demonstrating the random seed purpose, which is a key notion for explanation of the pseudo-random numbers generators.

complexitycourseerrorhandling mechanismadvancedObject-oriented programmingcompiler/warningassume no error will occur

Task 5 Implement a function that returns the address of a local variable. In the main() function print both the address and variable stored at that address.

int* getAddress()
{ int local = 42;return &local;}

Even though the example in Task 5 may look simple on the first glance, it actually introduces important notions, such as the call stack of functions. The example code will result in warning that it attempts to return the address of a local variable, and to understand why this is a serious error, the learner has to develop also knowledge about different memory sections of a program, static variables and dynamic variables. The mechanism of pointers is always a source of confusion for students even at more advanced level, and errors similar to the demonstrated above help the development of these complex notions.

complexitycourseerrorhandling mechanismAdvancedData structurescompiler/errorassume no error will occur

Task 6. Add a member function that returns the position of the parent node in a rooted tree. The function constructs Position objects from the parent pointer ptr_node->ptr_prnt and returns it as a result. Add a member function that returns a reference to the list of children nodes pointers. Omit the keyword typename in the implementation of the two functions:

template <typename TKey>
typename GTree<TKey>::Position
GTree<TKey>::Position::parent() const {. . .}
template <typename TKey>
list<typename GTree<TKey>::Node* >
&GTree<TKey>::Position::chldList() const {. . .}

Task 6 is a part of sequence of tasks that leads the learner towards the implementation of the general tree data structure that represents a rooted tree. The omitting of the keyword typename in the implementation of the two functions will produce a compile-time error whose understanding requires deeper knowledge of generic programming in C++.

complexitycourseerrorhandling mechanismadvancedData structuressemantic/data structureexceptions

Task 7. For our implementation of a priority queue, we will need a user-defined exception class that is derived from the standard runtime error. Consider the implementation below:

class PQueueExcept : public runtime_error
{ public:
PQueueExcept(const string &msg);
};
// parameter constructor
PQueueExcept::PQueueExcept(const string &msg)
: runtime_error(msg){}

What will happen if you access the minimum element of the priority queue, or you try to remove it from the data structure in the case when the container is empty?

// access the min element
template <typename TElm, typename TCmp>
const TElm &PQueue<TElm, TCmp>::min() const
{ return llist.front();}
// remove minimum element
template <typename TElm, typename TCmp>
void PQueue<TElm, TCmp>::removeMin()
{ llist.pop_front();}

The solution of Task7 is to throw exception of the user-defined type within the member functions of the class PQueue. The students are encouraged to provoke the errors that are common for the given data structure, and to protect their code from them using the mechanism of exceptions. The understanding of these types of errors also aids the development of the notion of the particular data structure and the method that is used to implement it.

5. Conclusions

EMT is a natural approach of teaching in computer programming courses. This is because of the significance and specific nature of computer programming errors which we can observe from the variety of error classification schemes and different methods to handle errors. On the other hand, the process of provoking errors during the educational process highly diminishes the negative emotional influence on the learners (Heimbeck et al. 2003), which enhances both the theoretical notion development and the practical skills.

As future work we plan to adopt the EMT using the techniques of testing and debugging aiming to enhance the development of notions needed in teaching algorithms on beginner and advanced levels. We also plan to develop a system of tasks that uses errors as an instrument for illustration of knowledge in our course in parallel computing, following the specific nature of errors in the implementation of parallel algorithms.

REFERENCES

ASENOVA, P.&MARINOV, M.,2018. Teaching mathematics with computer systems. Mathematics and Education in Mathematics. Proceedings of the Forty-seventh Spring Conference of the Union of Bulgarian Mathematicians, Borovets, April 2 – 6, 2018, 213 – 221.

ASENOVA, P.&MARINOV, M., 2019. System of tasks in mathematics education.Mathematics and Informatics,62(1), 52 – 70.

BOWEN, J. B., 1980.Standard error classification to support software reliability assessment. Proceedings of the National Computer Conference AFIPS’80, 697 – 705.

doi:10.1145/1500518.1500638

COHEN, B., 1994. The use of “bug” in computing. IEEE Annals of the History of Computing,16(2), 54 – 55.

DYRE, L., TABOR, A., RINGSTED, C.& TOLSGAARD, M. G., 2017. Imperfect practice makes perfect:error management training improves transfer of learning. Medical Education, 51(2), 196 – 206.

ECKEL, B, 2011.On Java 8, Version 2, Lean Publishing. http://leanpub. com/onjava8.

ENG, L. Z., 2019.Qt5 C++ GUI Programming Cookbook, 2nd edn, PACKT Publishing.

ETTLES, A., LUXTON-REILLY, A.& DENNY, P., 2018.Common logic errors made by novice programmers. Proceedings of the 20th Australasian Computing Education Conference ACE’18, 83 – 89.

FRESE, M., 1995. Error management in training: conceptual and empirical results.Organizational Learning and Technological Change,16(2), 112 – 124.

HEIMBECK, D., FRESE, M., SONNENTAG, S.&KEITH, N., 2003, Integrating errors into the trainingprocess: the function of error management instructions and the role of goal orientation. PersonnelPsychology,56(2), 333 – 361.

HORSTMANN, C., 2019.Big Java: early objects, 7th edn. Wiley.

HORSTMANN, C.& BUDD, T., 2008.Big C++, 2nd edn. Wiley.

KEITH, N.&FRESE, M.,2005. Self-regulation in error management training: emotion control and metacognition as mediators of performance effects.The journal of applied psychology, 90, 677 – 691.

KEITH, N. & FRESE, M.,2008. Effectiveness of error management training: a meta-analysis.The journal of applied psychology,93(1), 59 – 69.

KNUTH, D. E.,1989, The errors of tex.Software: practice and experience,19(7), 607 – 685.

KO, A. J. & MYERS, B. A., 2003.Development and evaluation of a model of programming errors.Proceedings of IEEE Symposium on Human Centric Computing Languages and Environments, 7 – 14.

KO, A. J. & MYERS, B. A.,2005. A framework and methodology for studying the causes of softwareerrors in programming systems. Journal of Visual Languages & Computing, 16 (1 – 2), 41 – 84.

KOENIG, A. AND STROUSTRUP, B., 1990. Exception handling for C++’, Jornal of Object-Oriented Programming, 3(2), 16 – 33.

LASKOV, L. M., 2016.Programming in C++, examples and solutions, part one: From procedural towards object-oriented paradigm, 1st edn. New Bulgarian University.

LASKOV, L. M., 2021.Introduction to computer programming through a system of tasks.Mathematicsand Informatics, 64 (6), 634 – 649.

MOTLEY, R. AND BROOKS, W. D., 1977.Statistical prediction of programming errors. ADA041106, Technical report, IBM Corporation. https://apps.dtic.mil/sti/pdfs/ADA041106.pdf

STROUSTRUP, B., 2014. Programming: principles and practice using C++, 2nd edn, Addison-Wesley Professional.

STROUSTRUP, B., 2019.C++ exceptions and alternatives.P1947 Technical report, C++ Standards Committee Papers [online].

http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2019/p1947r0.pdf.

SUTTER, H., 2019. Zero-overhead deterministic exceptions: throwing values.P0709 Technical report, C++ Standards Committee Papers [online].

http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2019/p0709r4.pdf.

2025 година
Книжка 6
ENHANCING STUDENT MOTIVATION AND ACHIEVEMENT THROUGH DIGITAL MIND MAPPING

Mikloš Kovač, Mirjana Brdar, Goran Radojev, Radivoje Stojković

OPTIMIZATION VS BOOSTING: COMPARISON OF STRATEGIES ON EDUCATIONAL DATASETS TO EXPLORE LOW-PERFORMING AT-RISK AND DROPOUT STUDENTS

Ranjit Paul, Asmaa Mohamed, Peren Jerfi Canatalay, Ashima Kukkar, Sadiq Hussain, Arun K. Baruah, Jiten Hazarika, Silvia Gaftandzhieva, Esraa A. Mahareek, Abeer S. Desuky, Rositsa Doneva

ARTIFICIAL INTELLIGENCE AS A TOOL FOR PEDAGOGICAL INNOVATIONS IN MATHEMATICS EDUCATION

Stanka Hadzhikoleva, Maria Borisova, , Borislava Kirilova

Книжка 4
Книжка 3
МОДЕЛИ НА ВЕРОЯТНОСТНИ ПРОСТРАНСТВА В ОЛИМПИАДНИ ЗАДАЧИ

Драгомир Грозев, Станислав Харизанов

Книжка 1
A NOTE ON A GENERALIZED DYNAMICAL SYSTEM OCCURS IN MODELLING “THE BATTLE OF THE SEXES”: CHAOS IN SOCIOBIOLOGY

Nikolay Kyurkchiev, Anton Iliev, Vesselin Kyurkchiev, Angel Golev, Todorka Terzieva, Asen Rahnev

EDUCATIONAL RESOURCES FOR STUDYING MIDSEGMENTS OF TRIANGLE AND TRAPEZOID

Toni Chehlarova1), Neda Chehlarova2), Georgi Gachev

2024 година
Книжка 6
ВЪЗМОЖНОСТИ ЗА ИЗГРАЖДАНЕ НА МЕЖДУПРЕДМЕТНИ ВРЪЗКИ МАТЕМАТИКА – ИНФОРМАТИКА

Елена Каращранова, Ирена Атанасова, Надежда Борисова

Книжка 5
FRAMEWORK FOR DESIGNING VISUALLY ORIENTATED TOOLS TO SUPPORT PROJECT MANAGEMENT

Dalibor Milev, Nadezhda Borisova, Elena Karashtranova

3D ОБРАЗОВАТЕЛЕН ПОДХОД В ОБУЧЕНИЕТО ПО СТЕРЕОМЕТРИЯ

Пеньо Лебамовски, Марияна Николова

Книжка 4
DYNAMICS OF A NEW CLASS OF OSCILLATORS: MELNIKOV’S APPROACH, POSSIBLE APPLICATION TO ANTENNA ARRAY THEORY

Nikolay Kyurkchiev, Tsvetelin Zaevski, Anton Iliev, Vesselin Kyurkchiev, Asen Rahnev

Книжка 3
РАЗСТОЯНИЯ МЕЖДУ ЗАБЕЛЕЖИТЕЛНИ ТОЧКИ И НЕРАВЕНСТВА В ИЗПЪКНАЛ ЧЕТИРИЪГЪЛНИК

Йордан Табов, Станислав Стефанов, Красимир Кънчев, Хаим Хаимов

USING AI TO IMPROVE ANSWER EVALUATION IN AUTOMATED EXAMS

Georgi Cholakov, Asya Stoyanova-Doycheva

Книжка 2
ON INTEGRATION OF STEM MODULES IN MATHEMATICS EDUCATION

Elena Karashtranova, Aharon Goldreich, Nadezhda Borisova

Книжка 1
STUDENT SATISFACTION WITH THE QUALITY OF A BLENDED LEARNING COURSE

Silvia Gaftandzhieva, Rositsa Doneva, Sadiq Hussain, Ashis Talukder, Gunadeep Chetia, Nisha Gohain

MODERN ROAD SAFETY TRAINING USING GAME-BASED TOOLS

Stefan Stavrev, Ivelina Velcheva

ARTIFICIAL INTELLIGENCE FOR GOOD AND BAD IN CYBER AND INFORMATION SECURITY

Nikolay Kasakliev, Elena Somova, Margarita Gocheva

2023 година
Книжка 6
QUALITY OF BLENDED LEARNING COURSES: STUDENTS’ PERSPECTIVE

Silvia Gaftandzhieva, Rositsa Doneva, Sadiq Hussain, Ashis Talukder, Gunadeep Chetia, Nisha Gohain

МОДЕЛ НА ЛЕОНТИЕВ С MS EXCEL

Велика Кунева, Мариян Милев

Книжка 5
AREAS ASSOCIATED TO A QUADRILATERAL

Oleg Mushkarov, Nikolai Nikolov

ON THE DYNAMICS OF A ClASS OF THIRD-ORDER POLYNOMIAL DIFFERENCE EQUATIONS WITH INFINITE NUMBER OF PERIOD-THREE SOLUTIONS

Jasmin Bektešević, Vahidin Hadžiabdić, Midhat Mehuljić, Sadjit Metović, Haris Lulić

СИСТЕМА ЗА ИЗВЛИЧАНЕ И ВИЗУАЛИЗАЦИЯ НА ДАННИ ОТ ИНТЕРНЕТ

Георги Чолаков, Емил Дойчев, Светла Коева

Книжка 4
MULTIPLE REPRESENTATIONS OF FUNCTIONS IN THE FRAME OF DISTANCE LEARNING

Radoslav Božić, Hajnalka Peics, Aleksandar Milenković

INTEGRATED LESSONS IN CALCULUS USING SOFTWARE

Pohoriliak Oleksandr, Olga Syniavska, Anna Slyvka-Tylyshchak, Antonina Tegza, Alexander Tylyshchak

Книжка 3
ПРИЛОЖЕНИЕ НА ЕЛЕМЕНТИ ОТ ГЕОМЕТРИЯТА НА ЧЕТИРИЪГЪЛНИКА ЗА РЕШАВАНЕ НА НЕСТАНДАРТНИ ЗАДАЧИ

Йордан Табов, Веселин Ненков, Асен Велчев, Станислав Стефанов

Книжка 2
Книжка 1
НОВА ФОРМУЛА ЗА ЛИЦЕ НА ЧЕТИРИЪГЪЛНИК (ЧЕТИВО ЗА VII КЛАС)

Йордан Табов, Асен Велчев, Станислав Стефанов, Хаим Хаимов

2022 година
Книжка 6
MOBILE GAME-BASED MATH LEARNING FOR PRIMARY SCHOOL

Margarita Gocheva, Nikolay Kasakliev, Elena Somova

Книжка 5
SECURITY ANALYSIS ON CONTENT MANAGEMENT SYSTEMS

Lilyana Petkova, Vasilisa Pavlova

MONITORING OF STUDENT ENROLMENT CAMPAIGN THROUGH DATA ANALYTICS TOOLS

Silvia Gaftandzhieva, Rositsa Doneva, Milen Bliznakov

TYPES OF SOLUTIONS IN THE DIDACTIC GAME “LOGIC MONSTERS”

Nataliya Hristova Pavlova, Michaela Savova Toncheva

Книжка 4
PERSONAL DATA PROCESSING IN A DIGITAL EDUCATIONAL ENVIRONMENT

Evgeniya Nikolova, Mariya Monova-Zheleva, Yanislav Zhelev

Книжка 3
Книжка 2
STEM ROBOTICS IN PRIMARY SCHOOL

Tsanko Mihov, Gencho Stoitsov, Ivan Dimitrov

A METAGRAPH MODEL OF CYBER PROTECTION OF AN INFORMATION SYSTEM

Emiliya Koleva, Evgeni Andreev, Mariya Nikolova

Книжка 1
CONVOLUTIONAL NEURAL NETWORKS IN THE TASK OF IMAGE CLASSIFICATION

Larisa Zelenina, Liudmila Khaimina, Evgenii Khaimin, D. Khripunov, Inga Zashikhina

INNOVATIVE PROPOSALS FOR DATABASE STORAGE AND MANAGEMENT

Yulian Ivanov Petkov, Alexandre Ivanov Chikalanov

APPLICATION OF MATHEMATICAL MODELS IN GRAPHIC DESIGN

Ivaylo Staribratov, Nikol Manolova

РЕШЕНИЯ НА КОНКУРСНИ ЗАДАЧИ БРОЙ 6, 2021 Г.

Задача 1. Дадени са различни естествени числа, всяко от които има прос- ти делители, не по-големи от . Докажете, че произведението на някои три от тези числа е точен куб. Решение: числата са представим във вида . Нека разгледаме квадрат

2021 година
Книжка 6
E-LEARNING DURING COVID-19 PANDEMIC: AN EMPIRICAL RESEARCH

Margarita Gocheva, Nikolay Kasakliev, Elena Somova

Книжка 5
ПОДГОТОВКА ЗА XXV МЛАДЕЖКА БАЛКАНИАДА ПО МАТЕМАТИКА 2021

Ивайло Кортезов, Емил Карлов, Мирослав Маринов

EXCEL’S CALCULATION OF BASIC ASSETS AMORTISATION VALUES

Vehbi Ramaj, Sead Rešić, Anes Z. Hadžiomerović

EDUCATIONAL ENVIRONMENT AS A FORM FOR DEVELOPMENT OF MATH TEACHERS METHODOLOGICAL COMPETENCE

Olha Matiash, Liubov Mykhailenko, Vasyl Shvets, Oleksandr Shkolnyi

Книжка 4
LEARNING ANALYTICS TOOL FOR BULGARIAN SCHOOL EDUCATION

Silvia Gaftandzhieva, Rositsa Doneva, George Pashev, Mariya Docheva

Книжка 3
THE PROBLEM OF IMAGES’ CLASSIFICATION: NEURAL NETWORKS

Larisa Zelenina, Liudmila Khaimina, Evgenii Khaimin, D. Khripunov, Inga Zashikhina

MIDLINES OF QUADRILATERAL

Sead Rešić, Maid Omerović, Anes Z. Hadžiomerović, Ahmed Palić

ВИРТУАЛЕН ЧАС ПО МАТЕМАТИКА

Севдалина Георгиева

Книжка 2
MOBILE MATH GAME PROTOTYPE ON THE BASE OF TEMPLATES FOR PRIMARY SCHOOL

Margarita Gocheva, Elena Somova, Nikolay Kasakliev, Vladimira Angelova

КОНКУРСНИ ЗАДАЧИ БРОЙ 2/2021 Г.

Краен срок за изпращане на решения: 0 юни 0 г.

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 1, 2021

Краен срок за изпращане на решения: 0 юни 0 г.

Книжка 1
СЕДЕМНАДЕСЕТА ЖАУТИКОВСКА ОЛИМПИАДА ПО МАТЕМАТИКА, ИНФОРМАТИКА И ФИЗИКА АЛМАТИ, 7-12 ЯНУАРИ 2021

Диян Димитров, Светлин Лалов, Стефан Хаджистойков, Елена Киселова

ОНЛАЙН СЪСТЕЗАНИЕ „VIVA МАТЕМАТИКА С КОМПЮТЪР“

Петър Кендеров, Тони Чехларова, Георги Гачев

2020 година
Книжка 6
ABSTRACT DATA TYPES

Lasko M. Laskov

Книжка 5
GAMIFICATION IN CLOUD-BASED COLLABORATIVE LEARNING

Denitza Charkova, Elena Somova, Maria Gachkova

NEURAL NETWORKS IN A CHARACTER RECOGNITION MOBILE APPLICATION

L.I. Zelenina, L.E. Khaimina, E.S. Khaimin, D.I. Antufiev, I.M. Zashikhina

APPLICATIONS OF ANAGLIFIC IMAGES IN MATHEMATICAL TRAINING

Krasimir Harizanov, Stanislava Ivanova

МЕТОД НА ДЕЦАТА В БЛОКА

Ивайло Кортезов

Книжка 4
TECHNOLOGIES AND TOOLS FOR CREATING ADAPTIVE E-LEARNING CONTENT

Todorka Terzieva, Valya Arnaudova, Asen Rahnev, Vanya Ivanova

Книжка 3
MATHEMATICAL MODELLING IN LEARNING OUTCOMES ASSESSMENT (BINARY MODEL FOR THE ASSESSMMENT OF STUDENT’S COMPETENCES FORMATION)

L. E. Khaimina, E. A. Demenkova, M. E. Demenkov, E. S. Khaimin, L. I. Zelenina, I. M. Zashikhina

PROBLEMS 2 AND 5 ON THE IMO’2019 PAPER

Sava Grozdev, Veselin Nenkov

Книжка 2
ЗА ВЕКТОРНОТО ПРОСТРАНСТВО НА МАГИЧЕСКИТЕ КВАДРАТИ ОТ ТРЕТИ РЕД (В ЗАНИМАТЕЛНАТА МАТЕМАТИКА)

Здравко Лалчев, Маргарита Върбанова, Мирослав Стоимиров, Ирина Вутова

КОНКУРЕНТНИ ПЕРПЕНДИКУЛЯРИ, ОПРЕДЕЛЕНИ ОТ ПРАВИЛНИ МНОГОЪГЪЛНИЦИ

Йоана Христова, Геновева Маринова, Никола Кушев, Светослав Апостолов, Цветомир Иванов

A NEW PROOF OF THE FEUERBACH THEOREM

Sava Grozdev, Hiroshi Okumura, Deko Dekov

PROBLEM 3 ON THE IMO’2019 PAPER

Sava Grozdev, Veselin Nenkov

Книжка 1
GENDER ISSUES IN VIRTUAL TRAINING FOR MATHEMATICAL KANGAROO CONTEST

Mark Applebaum, Erga Heller, Lior Solomovich, Judith Zamir

KLAMKIN’S INEQUALITY AND ITS APPLICATION

Šefket Arslanagić, Daniela Zubović

НЯКОЛКО ПРИЛОЖЕНИЯ НА ВЪРТЯЩАТА ХОМОТЕТИЯ

Сава Гроздев, Веселин Ненков

2019 година
Книжка 6
DISCRETE MATHEMATICS AND PROGRAMMING – TEACHING AND LEARNING APPROACHES

Mariyana Raykova, Hristina Kostadinova, Stoyan Boev

CONVERTER FROM MOODLE LESSONS TO INTERACTIVE EPUB EBOOKS

Martin Takev, Elena Somova, Miguel Rodríguez-Artacho

ЦИКЛОИДА

Аяпбергенов Азамат, Бокаева Молдир, Чурымбаев Бекнур, Калдыбек Жансуйген

КАРДИОИДА

Евгений Воронцов, Никита Платонов

БОЛГАРСКАЯ ОЛИМПИАДА ПО ФИНАНСОВОЙ И АКТУАРНОЙ МАТЕМАТИКЕ В РОССИИ

Росен Николаев, Сава Гроздев, Богдана Конева, Нина Патронова, Мария Шабанова

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Задача 1. Да се намерят всички полиноми, които за всяка реална стойност на удовлетворяват равенството Татяна Маджарова, Варна Задача 2. Правоъгълният триъгълник има остри ъгли и , а центърът на вписаната му окръжност е . Точката , лежаща в , е такава, че и . Симетралите

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 1, 2019

Задача 1. Да се намерят всички цели числа , за които

Книжка 5
ДЪЛБОКО КОПИЕ В C++ И JAVA

Христина Костадинова, Марияна Райкова

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Задача 1. Да се намери безкрайно множество от двойки положителни ра- ционални числа Милен Найденов, Варна

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 6, 2018

Задача 1. Точката е левият долен връх на безкрайна шахматна дъска. Една муха тръгва от и се движи само по страните на квадратчетата. Нека е общ връх на някои квадратчета. Казва- ме, че мухата изминава пътя между и , ако се движи само надясно и нагоре. Ако точките и са противоположни върхове на правоъгълник , да се намери броят на пътищата, свърз- ващи точките и , по които мухата може да мине, когато: а) и ; б) и ; в) и

Книжка 4
THE REARRANGEMENT INEQUALITY

Šefket Arslanagić

АСТРОИДА

Борислав Борисов, Деян Димитров, Николай Нинов, Теодор Христов

COMPUTER PROGRAMMING IN MATHEMATICS EDUCATION

Marin Marinov, Lasko Laskov

CREATING INTERACTIVE AND TRACEABLE EPUB LEARNING CONTENT FROM MOODLE COURSES

Martin Takev, Miguel Rodríguez-Artacho, Elena Somova

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Задача 1. Да се реши уравнението . Христо Лесов, Казанлък Задача 2. Да се докаже, че в четириъгълник с перпендикулярни диагонали съществува точка , за която са изпълнени равенствата , , , . Хаим Хаимов, Варна Задача 3. В правилен 13-ъгълник по произволен начин са избрани два диа- гонала. Каква е вероятността избраните диагонали да не се пресичат? Сава Гроздев, София, и Веселин Ненков, Бели Осъм

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 5, 2018

Задача 1. Ако и са съвършени числа, за които целите части на числата и са равни и различни от нула, да се намери .

Книжка 3
RESULTS OF THE FIRST WEEK OF CYBERSECURITY IN ARKHANGELSK REGION

Olga Troitskaya, Olga Bezumova, Elena Lytkina, Tatyana Shirikova

DIDACTIC POTENTIAL OF REMOTE CONTESTS IN COMPUTER SCIENCE

Natalia Sofronova, Anatoliy Belchusov

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Краен срок за изпращане на решения 30 ноември 2019 г.

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 4, 2018

Задача 1. Да се намерят всички тройки естествени числа е изпълнено равенството: а)

Книжка 2
ЕЛЕКТРОНЕН УЧЕБНИК ПО ОБЗОРНИ ЛЕКЦИИ ЗА ДЪРЖАВЕН ИЗПИТ В СРЕДАТА DISPEL

Асен Рахнев, Боян Златанов, Евгения Ангелова, Ивайло Старибратов, Валя Арнаудова, Слав Чолаков

ГЕОМЕТРИЧНИ МЕСТА, ПОРОДЕНИ ОТ РАВНОСТРАННИ ТРИЪГЪЛНИЦИ С ВЪРХОВЕ ВЪРХУ ОКРЪЖНОСТ

Борислав Борисов, Деян Димитров, Николай Нинов, Теодор Христов

ЕКСТРЕМАЛНИ СВОЙСТВА НА ТОЧКАТА НА ЛЕМОАН В ЧЕТИРИЪГЪЛНИК

Веселин Ненков, Станислав Стефанов, Хаим Хаимов

A TRIANGLE AND A TRAPEZOID WITH A COMMON CONIC

Sava Grozdev, Veselin Nenkov

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Христо Лесов, Казанлък Задача 2. Окръжност с диаметър и правоъгълник с диагонал имат общ център. Да се докаже, че за произволна точка M от е изпълне- но равенството . Милен Найденов, Варна Задача 3. В изпъкналия четириъгълник са изпълнени равенства- та и . Точката е средата на диагонала , а , , и са ортоганалните проекции на съответно върху правите , , и . Ако и са средите съответно на отсечките и , да се докаже, че точките , и лежат на една права.

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 3, 2018

Задача 1. Да се реши уравнението . Росен Николаев, Дико Суружон, Варна Решение. Въвеждаме означението , където . Съгласно това означение разлежданото уравнение придобива вида не е решение на уравнението. Затова са възможни само случаите 1) и 2) . Разглеж- даме двата случая поотделно. Случай 1): при е изпълнено равенството . Тогава имаме:

Книжка 1
PROBLEM 6. FROM IMO’2018

Sava Grozdev, Veselin Nenkov

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 2, 2018

Задача 1. Да се намери най-малкото естествено число , при което куба с целочислени дължини на ръбовете в сантиметри имат сума на обемите, рав- на на Христо Лесов, Казанлък Решение: тъй като , то не е куб на ес- тествено число и затова . Разглеждаме последователно случаите за . 1) При разглеждаме естествени числа и , за които са изпълнени релациите и . Тогава то , т.е. . Освен това откъдето , т.е. .Така получихме, че . Лесно се проверява, че при и няма естествен

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Задача 1. Да се намерят всички цели числа , за които

2018 година
Книжка 6
„ЭНЦИКЛОПЕДИЯ ЗАМЕЧАТЕЛЬНЫХ ПЛОСКИХ КРИВЫХ“ – МЕЖДУНАРОДНЫЙ СЕТЕВОЙ ИССЛЕДОВАТЕЛЬСКИЙ ПРОЕКТ В РАМКАХ MITE

Роза Атамуратова, Михаил Алфёров, Марина Белорукова, Веселин Ненков, Валерий Майер, Генадий Клековкин, Раиса Овчинникова, Мария Шабанова, Александр Ястребов

A NEW MEANING OF THE NOTION “EXPANSION OF A NUMBER”

Rosen Nikolaev, Tanka Milkova, Radan Miryanov

Книжка 5
ИТОГИ ПРОВЕДЕНИЯ ВТОРОЙ МЕЖДУНАРОДНОЙ ОЛИМПИАДЬI ПО ФИНАНСОВОЙ И АКТУАРНОЙ МАТЕМАТИКЕ СРЕДИ ШКОЛЬНИКОВ И СТУДЕНТОВ

Сава Гроздев, Росен Николаев, Мария Шабанова, Лариса Форкунова, Нина Патронова

LEARNING AND ASSESSMENT BASED ON GAMIFIED E-COURSE IN MOODLE

Mariya Gachkova, Martin Takev, Elena Somova

УЛИТКА ПАСКАЛЯ

Дарья Коптева, Ксения Горская

КОМБИНАТОРНИ ЗАДАЧИ, СВЪРЗАНИ С ТРИЪГЪЛНИК

Росен Николаев, Танка Милкова, Катя Чалъкова

Книжка 4
ЗА ПРОСТИТЕ ЧИСЛА

Сава Гроздев, Веселин Ненков

ИНЦЕНТЪР НА ЧЕТИРИЪГЪЛНИК

Станислав Стефанов

ЭПИЦИКЛОИДА

Инкар Аскар, Камила Сарсембаева

ГИПОЦИКЛОИДА

Борислав Борисов, Деян Димитров, Иван Стефанов, Николай Нинов, Теодор Христов

Книжка 3
ПОЛИНОМИ ОТ ТРЕТА СТЕПЕН С КОЛИНЕАРНИ КОРЕНИ

Сава Гроздев, Веселин Ненков

ЧЕТИРИДЕСЕТ И ПЕТА НАЦИОНАЛНА СТУДЕНТСКА ОЛИМПИАДА ПО МАТЕМАТИКА

Сава Гроздев, Росен Николаев, Станислава Стоилова, Веселин Ненков

Книжка 2
TWO INTERESTING INEQUALITIES FOR ACUTE TRIANGLES

Šefket Arslanagić, Amar Bašić

ПЕРФЕКТНА ИЗОГОНАЛНОСТ В ЧЕТИРИЪГЪЛНИК

Веселин Ненков, Станислав Стефанов, Хаим Хаимов

НЯКОИ ТИПОВЕ ЗАДАЧИ СЪС СИМЕТРИЧНИ ЧИСЛА

Росен Николаев, Танка Милкова, Радан Мирянов

Книжка 1
Драги читатели,

където тези проценти са наполовина, в Източна Европа те са около 25%, в

COMPUTER DISCOVERED MATHEMATICS: CONSTRUCTIONS OF MALFATTI SQUARES

Sava Grozdev, Hiroshi Okumura, Deko Dekov

ВРЪЗКИ МЕЖДУ ЗАБЕЛЕЖИТЕЛНИ ТОЧКИ В ЧЕТИРИЪГЪЛНИКА

Станислав Стефанов, Веселин Ненков

КОНКУРСНИ ЗАДАЧИ НА БРОЯ

Задача 2. Да се докаже, че всяка от симедианите в триъгълник с лице разделя триъгълника на два триъгълника, лицата на които са корени на урав- нението където и са дължините на прилежащите на симедианата страни на три- ъгълника. Милен Найденов, Варна Задача 3. Четириъгълникът е описан около окръжност с център , като продълженията на страните му и се пресичат в точка . Ако е втората пресечна точка на описаните окръжности на триъгълниците и , да се докаже, че Хаим Х

РЕШЕНИЯ НА ЗАДАЧИТЕ ОТ БРОЙ 2, 2017

Задача 1. Да се определи дали съществуват естествени числа и , при които стойността на израза е: а) куб на естествено число; б) сбор от кубовете на две естествени числа; в) сбор от кубовете на три естествени числа. Христо Лесов, Казанлък Решение: при и имаме . Следова- телно случай а) има положителен отговор. Тъй като при число- то се дели на , то при и имаме е естестве- но число. Следователно всяко число от разглеждания вид при деление на дава ос

2017 година
Книжка 6
A SURVEY OF MATHEMATICS DISCOVERED BY COMPUTERS. PART 2

Sava Grozdev, Hiroshi Okumura, Deko Dekov

ТРИ ИНВАРИАНТЫ В ОДНУ ЗАДА

Ксения Горская, Дарья Коптева, Асхат Ермекбаев, Арман Жетиру, Азат Бермухамедов, Салтанат Кошер, Лили Стефанова, Ирина Христова, Александра Йовкова

GAMES WITH

Aldiyar Zhumashov

SOME NUMERICAL SQUARE ROOTS (PART TWO)

Rosen Nikolaev, Tanka Milkova, Yordan Petkov

ЗАНИМАТЕЛНИ ЗАДАЧИ ПО ТЕМАТА „КАРТИННА ГАЛЕРИЯ“

Мирослав Стоимиров, Ирина Вутова

Книжка 5
ВТОРОЙ МЕЖДУНАРОДНЫЙ СЕТЕВОЙ ИССЛЕДОВАТЕЛЬСКИЙ ПРОЕКТ УЧАЩИХСЯ В РАМКАХ MITE

Мария Шабанова, Марина Белорукова, Роза Атамуратова, Веселин Ненков

SOME NUMERICAL SEQUENCES CONCERNING SQUARE ROOTS (PART ONE)

Rosen Nikolaev, Tanka Milkova, Yordan Petkov

Книжка 4
ГЕНЕРАТОР НА ТЕСТОВЕ

Ангел Ангелов, Веселин Дзивев

INTERESTING PROOFS OF SOME ALGEBRAIC INEQUALITIES

Šefket Arslanagić, Faruk Zejnulahi

PROBLEMS ON THE BROCARD CIRCLE

Sava Grozdev, Hiroshi Okumura, Deko Dekov

ПРИЛОЖЕНИЕ НА ЛИНЕЙНАТА АЛГЕБРА В ИКОНОМИКАТА

Велика Кунева, Захаринка Ангелова

СКОРОСТТА НА СВЕТЛИНАТА

Сава Гроздев, Веселин Ненков

Книжка 3
НЯКОЛКО ПРИЛОЖЕНИЯ НА ТЕОРЕМАТА НА МЕНЕЛАЙ ЗА ВПИСАНИ ОКРЪЖНОСТИ

Александра Йовкова, Ирина Христова, Лили Стефанова

НАЦИОНАЛНА СТУДЕНТСКА ОЛИМПИАДА ПО МАТЕМАТИКА

Сава Гроздев, Росен Николаев, Веселин Ненков

СПОМЕН ЗА ПРОФЕСОР АНТОН ШОУРЕК

Александра Трифонова

Книжка 2
ИЗКУСТВЕНА ИМУННА СИСТЕМА

Йоанна Илиева, Селин Шемсиева, Светлана Вълчева, Сюзан Феимова

ВТОРИ КОЛЕДЕН ЛИНГВИСТИЧЕН ТУРНИР

Иван Держански, Веселин Златилов

Книжка 1
ГЕОМЕТРИЯ НА ЧЕТИРИЪГЪЛНИКА, ТОЧКА НА МИКЕЛ, ИНВЕРСНА ИЗОГОНАЛНОСТ

Веселин Ненков, Станислав Стефанов, Хаим Хаимов

2016 година
Книжка 6
ПЕРВЫЙ МЕЖДУНАРОДНЫЙ СЕТЕВОЙ ИССЛЕДОВАТЕЛЬСКИЙ ПРОЕКТ УЧАЩИХСЯ В РАМКАХ MITE

Мария Шабанова, Марина Белорукова, Роза Атамуратова, Веселин Ненков

НЕКОТОРЫЕ ТРАЕКТОРИИ, КОТОРЫЕ ОПРЕДЕЛЕНЫ РАВНОБЕДРЕННЫМИ ТРЕУГОЛЬНИКАМИ

Ксения Горская, Дарья Коптева, Даниил Микуров, Еркен Мудебаев, Казбек Мухамбетов, Адилбек Темирханов, Лили Стефанова, Ирина Христова, Радина Иванова

ПСЕВДОЦЕНТЪР И ОРТОЦЕНТЪР – ЗАБЕЛЕЖИТЕЛНИ ТОЧКИ В ЧЕТИРИЪГЪЛНИКА

Веселин Ненков, Станислав Стефанов, Хаим Хаимов

FUZZY LOGIC

Reinhard Magenreuter

GENETIC ALGORITHM

Reinhard Magenreuter

Книжка 5
NEURAL NETWORKS

Reinhard Magenreuter

Книжка 4
АКТИВНО, УЧАСТВАЩО НАБЛЮДЕНИЕ – ТИП ИНТЕРВЮ

Христо Христов, Христо Крушков

ХИПОТЕЗАТА В ОБУЧЕНИЕТО ПО МАТЕМАТИКА

Румяна Маврова, Пенка Рангелова, Елена Тодорова

Книжка 3
ОБОБЩЕНИЕ НА ТЕОРЕМАТА НА ЧЕЗАР КОШНИЦА

Сава Гроздев, Веселин Ненков

Книжка 2
ОЙЛЕР-ВЕН ДИАГРАМИ ИЛИ MZ-КАРТИ В НАЧАЛНАТА УЧИЛИЩНА МАТЕМАТИКА

Здравко Лалчев, Маргарита Върбанова, Ирина Вутова, Иван Душков

ОБВЪРЗВАНЕ НА ОБУЧЕНИЕТО ПО АЛГЕБРА И ГЕОМЕТРИЯ

Румяна Маврова, Пенка Рангелова

Книжка 1
STATIONARY NUMBERS

Smaiyl Makyshov

МЕЖДУНАРОДНА ЖАУТИКОВСКА ОЛИМПИАДА

Сава Гроздев, Веселин Ненков

2015 година
Книжка 6
Книжка 5
Книжка 4
Книжка 3
МОТИВАЦИОННИТЕ ЗАДАЧИ В ОБУЧЕНИЕТО ПО МАТЕМАТИКА

Румяна Маврова, Пенка Рангелова, Зара Данаилова-Стойнова

Книжка 2
САМОСТОЯТЕЛНО РЕШАВАНЕ НА ЗАДАЧИ С EXCEL

Пламен Пенев, Диана Стефанова

Книжка 1
ГЕОМЕТРИЧНА КОНСТРУКЦИЯ НА КРИВА НА ЧЕВА

Сава Гроздев, Веселин Ненков

2014 година
Книжка 6
КОНКУРЕНТНОСТ, ПОРОДЕНА ОТ ТАНГЕНТИ

Сава Гроздев, Веселин Ненков

Книжка 5
ИНФОРМАТИКА В ШКОЛАХ РОССИИ

С. А. Бешенков, Э. В. Миндзаева

ОЩЕ ЕВРИСТИКИ С EXCEL

Пламен Пенев

ДВА ПОДХОДА ЗА ИЗУЧАВАНЕ НА УРАВНЕНИЯ В НАЧАЛНАТА УЧИЛИЩНА МАТЕМАТИКА

Здравко Лалчев, Маргарита Върбанова, Ирина Вутова

Книжка 4
ОБУЧЕНИЕ В СТИЛ EDUTAINMENT С ИЗПОЛЗВАНЕ НА КОМПЮТЪРНА ГРАФИКА

Христо Крушков, Асен Рахнев, Мариана Крушкова

Книжка 3
ИНВЕРСИЯТА – МЕТОД В НАЧАЛНАТА УЧИЛИЩНА МАТЕМАТИКА

Здравко Лалчев, Маргарита Върбанова

СТИМУЛИРАНЕ НА ТВОРЧЕСКА АКТИВНОСТ ПРИ БИЛИНГВИ ЧРЕЗ ДИНАМИЧЕН СОФТУЕР

Сава Гроздев, Диана Стефанова, Калина Василева, Станислава Колева, Радка Тодорова

ПРОГРАМИРАНЕ НА ЧИСЛОВИ РЕДИЦИ

Ивайло Старибратов, Цветана Димитрова

Книжка 2
ФРАКТАЛЬНЫЕ МЕТО

Валерий Секованов, Елена Селезнева, Светлана Шляхтина

Книжка 1
ЕВРИСТИКА С EXCEL

Пламен Пенев

SOME INEQUALITIES IN THE TRIANGLE

Šefket Arslanagić

2013 година
Книжка 6
Книжка 5
МАТЕМАТИЧЕСКИЕ РЕГАТЬI

Александр Блинков

Книжка 4
Книжка 3
АКАДЕМИК ПЕТЪР КЕНДЕРОВ НА 70 ГОДИНИ

чл. кор. Юлиан Ревалски

ОБЛАЧНИ ТЕХНОЛОГИИ И ВЪЗМОЖНОСТИ ЗА ПРИЛОЖЕНИЕ В ОБРАЗОВАНИЕТО

Сава Гроздев, Иванка Марашева, Емил Делинов

СЪСТЕЗАТЕЛНИ ЗАДАЧИ ПО ИНФОРМАТИКА ЗА ГРУПА Е

Ивайло Старибратов, Цветана Димитрова

Книжка 2
ЕКСПЕРИМЕНТАЛНАТА МАТЕМАТИКА В УЧИЛИЩЕ

Сава Гроздев, Борислав Лазаров

МАТЕМАТИКА С КОМПЮТЪР

Сава Гроздев, Деко Деков

ЕЛИПТИЧЕН АРБЕЛОС

Пролет Лазарова

Книжка 1
ФРАГМЕНТИ ОТ ПАМЕТТА

Генчо Скордев

2012 година
Книжка 6
ДВЕ ДИДАКТИЧЕСКИ СТЪЛБИ

Сава Гроздев, Светлозар Дойчев

ТЕОРЕМА НА ПОНСЕЛЕ ЗА ЧЕТИРИЪГЪЛНИЦИ

Сава Гроздев, Веселин Ненков

ИЗЛИЧАНЕ НА ОБЕКТИВНИ ЗНАНИЯ ОТ ИНТЕРНЕТ

Ивайло Пенев, Пламен Пенев

Книжка 5
ДЕСЕТА МЕЖДУНАРОДНА ОЛИМПИАДА ПО ЛИНГВИСТИКА

д–р Иван А. Держански (ИМИ–БАН)

ТЕОРЕМА НА ВАН ОБЕЛ И ПРИЛОЖЕНИЯ

Тодорка Глушкова, Боян Златанов

МАТЕМАТИЧЕСКИ КЛУБ „СИГМА” В СВЕТЛИНАТА НА ПРОЕКТ УСПЕХ

Сава Гроздев, Иванка Марашева, Емил Делинов

I N M E M O R I A M

На 26 септември 2012 г. след продължително боледуване ни напусна проф. дпн Иван Ганчев Донев. Той е първият професор и първият доктор на науките в България по методика на обучението по математика. Роден е на 6 май 1935 г. в с. Страхилово, В. Търновско. След завършване на СУ “Св. Кл. Охридски” става учител по математика в гр. Свищов. Тук той организира първите кръжоци и със- тезания по математика. През 1960 г. Иван Ганчев печели конкурс за асистент в СУ и още през следващата година започ

Книжка 4
Книжка 3
СЛУЧАЙНО СЪРФИРАНЕ В ИНТЕРНЕТ

Евгения Стоименова

Книжка 2
SEEMOUS OLYMPIAD FOR UNIVERSITY STUDENTS

Sava Grozdev, Veselin Nenkov

EUROMATH SCIENTIFIC CONFERENCE

Sava Grozdev, Veselin Nenkov

FIVE WAYS TO SOLVE A PROBLEM FOR A TRIANGLE

Šefket Arslanagić, Dragoljub Milošević

ПРОПОРЦИИ

Валя Георгиева

ПЪТЕШЕСТВИЕ В СВЕТА НА КОМБИНАТОРИКАТА

Росица Керчева, Румяна Иванова

ПОЛЗОТВОРНА ПРОМЯНА

Ивайло Старибратов

Книжка 1
ЗА ЕЛЕКТРОННОТО ОБУЧЕНИЕ

Даниела Дурева (Тупарова)

МАТЕМАТИКАТА E ЗАБАВНА

Веселина Вълканова

СРАВНЯВАНЕ НА ИЗРАЗИ С КВАДРАТНИ КОРЕНИ

Гинка Бизова, Ваня Лалева
