SEMI-EMPIRICAL COMPUTATIONAL STUDY OF THE LIGAND AND ITS METAL COMPLEXES DERIVED FROM 4- AMINOANTIPYRINE AND 2, 4-DIHYDROXY BENZOIC ACID

Резюме: Theoretical molecular structures of the ligand and its Co(II), Ni(II), Cu(II) and Zn(II) complexes have been studied using the semi-empirical quantum chemical methods. The experimental IR, electronic and NMR data of the investigated compounds are compared with the computational data. The ESP map and the natural atomic charge of the ligand was calculated to ascertain the reactive sites of the ligand. The experimental data agree well with the computational data.

Ключови думи: MEP; natural atomic charge; correlation coefficient; AM1; PM3

Introduction

Molecular modelling is an important aspect of computational chemistry because any molecular system which is difficult, dangerous, impossible to handle experimentally can be analysed computationally to get the stability, reactivity and geometrical pictures of the system. Molecular modelling is a quite accurate method in gathering data relating to geometric, electronic structures, vibration frequencies, chemical shifts, bond angles, bond distance (Mahmood et al., 2015). It is also providing information to increase the understanding of various biochemical processes such as enzymatic reactions, photosynthesis. The semi-empirical, ab-initio and DFT methods have been used in recent times successfully in predicting the geometrical, vibrational frequencies and chemical shifts of various chemical systems. It has been reported that the semi-empirical PM3 level of theory has predicted the IR frequencies of complex compounds more closely to experimental data than other methods (Topacli & Topacli, 2003). The structural model of a Al(III) complex has been confirmed due to a close agreement between the experimental and theoretical electronics spectral data (Sirichote et al.,1998).

The present theoretical study is based on the metal complexes of Co(II), Ni(II), Cu(II) and Zn(II) of azo dye ligand derived from 4-Aminoantipyrine and 2, 4-dihydroxy benzoic acid. The synthesis and characterisation of the ligand and its metal complexes has already been reported (Chaulia, 2016). The present study is concentrated on the theoretical study involving MEP study of the ligand, analysis of Mulliken charges of the ligand and comparison of the experimental vibration frequencies, chemical shifts and electronic spectra.

Computational methods

In this work, all the calculations were performed with the MOPAC programme Chem3D Molecular Modelling and Analysis Cambridge soft programme package.1) The structures of the investigated compounds were drawn using the same programme. The structure optimisation of the ligand and its metal complexes were performed by using the PM3 method with the RMS gradient 0.001.

Results and discussion

Natural atomic charge

The distribution of charges in a molecule determines electronic properties such as polarisability and dipole moment (Bejler et al., 1990). Hence, the atomic charges at different sites of the ligand was calculated using BLYP method using 3 – 21(d-p) basis set and summarised in the Table 1. Both oxygen and nitrogen atoms have the most electronegative natural charge but the oxygen atoms are more electronegative than the N atoms. The C6, C8, C10, C11, C12, C13, C19, C21 and C9 are electronegative as they away from the N and O atoms while other carbon atoms are electropositive. All the hydrogen atoms are also electropositive. Therefore, nitrogen atom of the azo group, oxygen atoms of the hydroxyl group(-OH) and carboxy (COOH) can act as the donor atoms. The metal can be coordinated to the ligand through the donor atoms (Figs. 1 and 2).

MEP study of the ligand

The electrostatic potential map(MEP) study of the ligand as given in the Fig. 3 was made to indentify the electrophilic and nucleophilic reactive sites present in the molecule (Politzer & Murray,1991). The map also gives information regarding charge distribution of the molecule. The MEP was calculated using BLYP method using 3 – 21(d-p) basis set. The red colour of the map reflects the reactive sites of electrophilic attack and the blue colour indicates the reactive sites of nucleophilic attack. It was seen from the map that negative region (red colour) is found over nitrogen atoms of the azo group and oxygen atoms of the hydroxyl (-OH) and acidic (-COOH) group. Hence, the metal ion can coordinate with the azo nitrogen and oxygen atoms of the hydroxyl(-OH) and acidic(-COOH) group of the ligand which is supported by the natural atomic charge.

IR study

The IR study the ligand and its metal complexes were undertaken in our previous study to characterise the investigated compounds, but in this study attempts has been made to compare the experimental vibration data with the computational data. Here semi-empirical study has been made using the force field AM1 (Dewar et al.,1985) and PM3 (Stewart, 1989) because semi-empirical models are less expensive and less time consuming and are providing the better results (Cornard & Merlin, 2003).

The IR spectrum of the ligand as given in the Fig. 4 shows a broad band at 3434 cm-1 due to the O-H stretching vibration. That band is missing from the spectra of the metal complexes as given in the Fig. 5 and Tables 2 and 3. The AM1 and PM3 force fields indicate vibrational frequencies at 3440 cm-1 and 3444 cm-1 respectively. The (C-O) vibration frequency of the ligand is observed at 1270 cm-1 but AM1 force field predicts it at 1279 cm-1 and PM3 force field indicates at 1257 cm-1. This (C-O) frequency is shifted to ~ 1236 cm-1 in metal complexes, the computational study for the Co(II) metal complex reveals it at 1199 cm-1 and 1226 cm-1 under the AM1 and PM3 force fields respectively, this fact confirms deprotonation of the phenolic(OH) group and the bonding between the metal ions and oxygen atoms. In the spectrum of the ligand, a band is seen at 1493 cm-1 due to (N=N) vibration but AM1 and PM3 force fields predicts at 1497 cm-1 and 1457 cm-1. This band is shifted to ~ 1456 cm-1 but computational study of Co(II) indicates at 1465 cm-1 under AM1 and PM3 force fields suggesting bonding between azo nitrogen and metal ions. The monodentate nature of –COOH group is confirmed from the band at 1411 cm-1 due - vibration and at 1632 cm-1 due to (COO-) vibration. The AMI force field at 1406 cm-1 and 1633 cm-1 and PM3 for asympredicts at 1366 cm-1 and 1579 cm-1 for to - and (COO-) vibrations. These bands observed in the spectra of to (COO- and at ~1621 cm-1 due to (COO-) stretching. The AM1 force field dicts it at 1364 at 1634 cm-1 for - - , However . All these observations confirm the bonding between the metal ions and oxygen atom of the carboxyl group.

1.60 1.5 1.4 1.3 1.2 1.1 1.0 0.9 0.8

A 0.7 0.6 0.5 0.4 0.3 0.2 0.1

0.00

Figure 5. IR spectrum of the Co(II) complex

The calculated and experimental vibration frequencies of the ligand have been compared as provided in the Figs. 6 and 7. The correlation coefficient between the vibration frequency calculated by AM1 method and the experimental data is 1, whereas the correlation coefficient between the vibration frequency calculated by PM3 method and the experimental data is 0.998 while the percentage variation in both the methods is less than 5.

The comparison between the experimental and calculated vibration frequency of the Co(II) has been made and it provides the correlation coefficient 0.999 and 0.996 for the AM1 and PM3 methods respectively (Figs. 8 – 11) and percentage variation for both methods is less than 5. It has been established from the experimental and calculated data that the ligand has been coordinated with the metal ions through azo nitrogen atom, oxygen atoms of the aromatic hydroxy and carboxylate group (Fig. 12).

NMR spectra

The computational NMR study of the ligand and its Zn(II) complexes were undertaken to predict the 1H chemical shifts (δ ppm) and the computational data were correlated with the experimental data (Torda & Van Gunsteren, 1992]. The gauge independent atomic orbital method has been used for calculating the NMR chemical shifts (Wolinski et al.,1990). The results predict the experimental NMR data are in good agreement with the calculated data of the ligand and its Zn(II) complex. A good correlation between the calculated and experimental chemical shifts was obtained with R2 = 0. 989 which is depicted in the Fig. 15.
